Deskripsi
HOBO Occupancy & Light data logger memantau ruangan dan perubahan cahaya dalam ruangan untuk mengidentifikasi dan menentukan penggunaan energi dan potensi penghematan. HOBO UX90-006 Room Occupancy / Light Data Logger tersedia dalam model memori standar 128 KB (UX90-006) yang mampu melakukan 84.650 pengukuran dan versi memori 512KB yang diperluas (UX90-006M) yang mampu melakukan lebih dari 346.795 pengukuran.
Fitur
- Mengukur ruangan hingga 12 meter
- Kalibrasi otomatis untuk memastikan pembacaan yang andal
- Layar LCD menampilkan kekuatan sinyal
- Aksesori pipa ringan yang menghilangkan efek cahaya sekitar untuk memastikan pembacaan yang paling akurat
- Kompatibel dengan perangkat lunak HOBOware dan HOBOware Pro untuk penyiapan, grafik, dan analisis logger
Spesifikasi
Occupancy Sensor
Detection Range
UX90-005x: maximum 5 m (15.4 ft);
UX90-006x: maximum 12 m (39.4 ft)
Detection Performance
UX90-005x: 94° (±47°) Horizontal; 82° (±41°) Vertical (see Figure A)
UX90-006x: 102° (±51°) Horizontal; 92° (±46°) Vertical (see Figure B)
Detection Zones
UX90-005x: 64 (see Figure A)
UX90-006x: 92 (see Figure B)
Light Sensor
Light threshold: > 65 lux
Light type: LED, CFL, fluorescent, HID, incandescent, natural
Logger
Time accuracy: ±1 minute per month at 25°C (77°F) (see Plot A)
Battery life: 1 year typical use
Memory
UX90-005/-006: 128 KB (84,650 measurements, maximum)
UX90-005M/-006M: 512 KB (346,795 measurements, maximum)
Download type: USB 2.0 interface
Download time: 10 seconds for 128 KB; 30 seconds for 512 KB
Logger Operating Range
Logging: -20° to 70°C (-4° to 158°F); 0 to 95% RH (non-condensing)
Launch/readout: 0° to 50°C (32° to 122°F) per USB specification
Occupancy sensor range: 20° to 60°C (-4° to 140°F); 15 to 85% RH (non-condensing)
LCD: LCD is visible from: 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range
Size
UX90-005x: 3.66 x 8.48 x 2.36 cm (1.44 x 3.34 x 0.93 in.)
UX90-006x: 3.66 x 8.48 x 2.87 cm (1.44 x 3.34 x 1.13 in.)
Weight: 30 g (1.06 oz)
Environmental rating: IP50
– The CE Marking identifies this product as complying with all relevant directives in the European Union (EU)
